Working area
Multipunch 1000 x 2000 mm 1060 x 2080 mm
Multipunch 1250 x 2500 mm 1310 x 2580 mm
Multipunch 1500 x 3000 mm 1560 x 3080 mm

Performance
Max. sheet thickness Choose Material Clamps for
either 7 mm (¼”) or 12.7 mm (½”)
Max. sheet length 9999 mm by repositioning
Max. hydraulic punching power 280 kN
Max. workpiece weight 200 kg

Speeds

Max. positioning speed X- axes 60 m/min
Max. positioning speed Y- axes 60 m/min
simultaneous X & Y 85 m/min
Max. strokes standard hydraulic 250 strokes/min
Max. strokes fast hydraulic 800 strokes/min

Axes accuracy during punching process
Positioning difference + - 0,10 mm
Repeatability + - 0,03 mm

Space requirement and weights
Multipunch 1000 x 2000 6100 x 5338 x 2100 mm weight 12500 kg
Multipunch 1250 x 2500 7000 x 5963 x 2100 mm weight 14000 kg
Multipunch 1500 x 3000 8060 x 6588 x 2100 mm weight 15800 kg

Electrical Values standard hydr./fast hydr.
Electrical connecting value 20 / 25 kVA
Hydraulic motor 4,8 / 11 kW
Electrical consumption 2 mm sheet thickness
continuous operation 4,9 / 7,7 kW/h
Electrical consumption 4 mm sheet thickness
continuous operation 5,4 / 8,75 kW/h
Required fuse 3 x 25 A / 3 x 35 A
