Info
Technical specifications
Technical Data:
|
Maximum press force |
320 |
tons |
|
Maximum bending length |
4.100 |
mm |
|
Maximum clear distance between uprights |
3.550 |
mm |
|
Maximum throat depth |
400 |
mm |
|
Approach speed |
120 |
mm / s |
|
Working speed |
10 |
mm / s |
|
Return speed |
90 |
mm / s |
|
Stroke |
280 |
mm |
|
Installation height |
515 |
mm |
|
Table width |
120 |
mm |
|
Height |
3.400 |
mm |
|
Width |
1.900 |
mm |
|
Length |
5.000 |
mm |
|
Drive power |
2 x 10 |
kW |
|
Maximum hydraulic pressure |
275 |
bar |
